| Model | SAW40DP | |
| WATER PUMP | Suction, discharge port diameter[mm(in)] | 100(4'') |
| Cont.head(m) | 31 | |
| Self-priming time(s/4m) | 180 | |
| Max suction head(m) | 8 | |
| Cont.capacity(m³/hr) | 96 | |
| ENGINE | Engine model | SAW186FA |
| Speed(rpm) | 3600 | |
| Fuel consumption(g/kw.h) | 280 | |
| Type | Single-cylinder,vertical,4-stroke air-cooled diesel engine | |
| Displacement(cc) | 418 | |
| Bore*stroke(mm) | 86*72 | |
| Starting system | Recoil or Electric | |
| Fuel tank capacity(L) | 5.5 | |
| STANDARD | Oil alert | yes |
| FEATURES | Connector of infall, Connector of outfall | yes |
| Filter | yes | |
| Seal ring | yes | |
| Hoop | yes | |
| DIMENSIONS | Dimension(L×W×H)(mm) | 645x475x605 |
| Net weight(kg) | 69 | |
| 20FT | 99 | |
